| Mfc |
Specified Power System
Reference Number |
Description |
| Sinexcel |
184-1010-100200 |
30kVA Wall-Mounted
bi-directional grid-interactive /off-grid energy storage
inverter, compatible with engine-generator based off-grid
systems (virtual synchronous generator - VSG), IP32/NEMA 1
with forced air cooling, battery operational range between
200VDC to 750VDC (de-rated AC output for battery voltages
between 200VDC to 350VDC), 480VAC 3 phase 60Hz input/output
[Non-Isolated (requires separate output isolation XFMR for
single phase loads)], 96.5% (CEC) efficiency, overload
ratings of 105 to 115% = 10min; 115 to 125% = 1min; 125 to
150% = 200ms, each inverter: 18.5"W x 25.98"H x 6.93"D, 94.8
Lbs., Certifications: ETL listed conforming to
UL1741/UL1741SA, CPUC, RULE 21, IEEE1547; Protection: OTP,
AC OVP/UVP, OFP/UFP, EPO, AC Phase Reverse, Fan/Relay
Failure, OLP, GFDI, Anti-islanding |
| Sinexcel |
184-1020-100100 |
50kVA Modular bi-directional
grid-interactive/off-grid energy storage inverter with local
touch-screen control, with Utility + PV connection,
compatible with engine-generator based off-grid systems
(virtual synchronous generator - VSG), equipped with (1)
PCS-AC-50k power conversion modules and built in transformer
for 3-phase 4-wire applications, IP20/NEMA 1 with forced air
cooling, PV input voltage range between 520 TO 800VDC (MPPT
controller based), battery operational range between 250VDC
TO 520VDC, 480VAC 3 phase 60Hz input/output [Isolated (built
in XFMR)], 95.5% efficiency, overload ratings of 105 to 115%
= 10min; 115 to 125% = 1min; 125 to 150% = 200ms, each
inverter: 31.5"W x 85.04"H x 31.5"D, 1146.4 Lbs.,
Certifications: UL1741 /UL 9540, CPUC RULE 21,IEEE1547,CSA
22.2; Protection: OTP, AC OVP/UVP, OFP/UFP, EPO, AC Phase
Reverse, Fan/Relay Failure, OLP, GFDI, Anti-islanding |
| Sinexcel |
184-1020-100200 |
100kVA rated (complete power
system frame only with no power modules) Modular
bi-directional grid-interactive/off-grid energy storage
inverter with local touch screen control, with Utility + PV
connection, compatible with engine-generator based off-grid
systems (virtual synchronous generator - VSG), equipped with
(0) PCS-AC-50k power conversion modules and built in
transformer for 3-phase 4-wire applications, IP20/NEMA 1
with forced air cooling, PV input voltage range between 520
TO 800VDC (MPPT controller based), battery operational range
between 250VDC TO 520VDC, 480VAC 3 phase 60Hz input/output
[Isolated (built in XFMR)], 95.5% efficiency, overload
ratings of 105 to 115% = 10min; 115 to 125% = 1min; 125 to
150% = 200ms, each inverter: 31.5"W x 85.04"H x 31.5"D,
1455.1 Lbs., Certifications: UL1741 /UL 9540, CPUC RULE
21,IEEE1547,CSA 22.2; Protection: OTP, AC OVP/UVP, OFP/UFP,
EPO, AC Phase Reverse, Fan/Relay Failure, OLP, GFDI,
Anti-islanding |
| Sinexcel |
184-1020-100300 |
50kVA (expandable to 100kVA
within same cabinet) Modular bi-directional
grid-interactive/off-grid energy storage inverter with local
touch screen control, with Utility + PV connection,
compatible with engine-generator based off-grid systems
(virtual synchronous generator - VSG), equipped with (1)
PCS-AC-50k power conversion modules and built in transformer
for 3-phase 4-wire applications, IP20/NEMA 1 with forced air
cooling, PV input voltage range between 520 TO 800VDC (MPPT
controller based), battery operational range between 250VDC
TO 520VDC, 480VAC 3 phase 60Hz input/output [Isolated (built
in XFMR)], 95.5% efficiency, overload ratings of 105 to 115%
= 10min; 115 to 125% = 1min; 125 to 150% = 200ms, each
inverter: 31.5"W x 85.04"H x 31.5"D, 1554.3 Lbs.,
Certifications: UL1741 /UL 9540, CPUC RULE 21,IEEE1547,CSA
22.2; Protection: OTP, AC OVP/UVP, OFP/UFP, EPO, AC Phase
Reverse, Fan/Relay Failure, OLP, GFDI, Anti-islanding |
| Sinexcel |
184-1020-100400 |
100kVA Modular bi-directional
grid-interactive/off-grid energy storage inverter with local
touch screen control, with Utility + PV connection,
compatible with engine-generator based off-grid systems
(virtual synchronous generator - VSG), equipped with (2)
PCS-AC-50k power conversion modules and built in transformer
for 3-phase 4-wire applications, IP20/NEMA 1 with forced air
cooling, PV input voltage range between 520 TO 800VDC (MPPT
controller based), battery operational range between 250VDC
TO 520VDC, 480VAC 3 phase 60Hz input/output [Isolated (built
in XFMR)], 95.5% efficiency, overload ratings of 105 to 115%
= 10min; 115 to 125% = 1min; 125 to 150% = 200ms, each
inverter: 31.5"W x 85.04"H x 31.5"D, 1653.5 Lbs.,
Certifications: UL1741 /UL 9540, CPUC RULE 21,IEEE1547,CSA
22.2; Protection: OTP, AC OVP/UVP, OFP/UFP, EPO, AC Phase
Reverse, Fan/Relay Failure, OLP, GFDI, Anti-islanding |
| Sinexcel |
184-1020-100500 |
50kVA Modular bi-directional
grid-interactive/off-grid energy storage inverter with local
touch screen control, compatible with engine-generator based
off-grid systems (virtual synchronous generator - VSG),
equipped with (1) PCS-AC-50k power conversion modules and
built in transformer for 3-phase 4-wire applications,
IP20/NEMA 1 with forced air cooling, battery operational
range between 500VDC to 850VDC, 480VAC 3 phase 60Hz input /
480VAC 3 phase 60Hz sinewave output, 94% (CEC) efficiency,
overload ratings of 105 to 115% = 10min; 115 to 125% = 1min;
125 to 150% = 200ms, each inverter: 31.5"W x 85.04"H x
31.5"D, 1025.1 Lbs., Certifications: ETL listed conforming
to UL1741/UL1741SA, UL9540, CPUC RULE 21, IEEE1547, HECO
RULE14H, CEC, CSA22.2, HECO CGS, HECO CSS; Protection: OTP,
AC OVP/UVP, OFP/UFP, EPO, AC Phase Reverse, Fan/Relay
Failure, OLP, GFDI, Anti-islanding |
| Sinexcel |
184-1020-100600 |
100kVA rated (complete Power
System Frame only with no power modules) Modular
bi-directional grid-interactive/off-grid energy storage
inverter with local touch screen control, compatible with
engine-generator based off-grid systems (virtual synchronous
generator - VSG), equipped with (0) PCS-AC-50k power
conversion module(s) and built in transformer for 3-phase
4-wire applications, IP20/NEMA 1 with forced air cooling,
battery operational range between 500VDC to 850VDC, 480VAC 3
phase 60Hz input / 480VAC 3 phase 60Hz sinewave output, 94%
(CEC) efficiency, overload ratings of 105 to 115% = 10min;
115 to 125% = 1min; 125 to 150% = 200ms, each inverter:
31.5"W x 85.04"H x 31.5"D, 1300.7 Lbs., Certifications: ETL
listed conforming to UL1741/UL1741SA, UL9540, CPUC RULE 21,
IEEE1547, HECO RULE14H, CEC, CSA22.2, HECO CGS, HECO CSS;
Protection: OTP, AC OVP/UVP, OFP/UFP, EPO, AC Phase Reverse,
Fan/Relay Failure, OLP, GFDI, Anti-islanding |
| Sinexcel |
184-1020-100700 |
50kVA (expandable to 100kVA)
Modular bi-directional grid-interactive/off-grid energy
storage inverter with local touch screen control, compatible
with engine-generator based off-grid systems (virtual
synchronous generator - VSG), equipped with (1) PCS-AC-50k
power conversion module(s) and built in transformer for
3-phase 4-wire applications, IP20/NEMA 1 with forced air
cooling, battery operational range between 500VDC to 850VDC,
480VAC 3 phase 60Hz input / 480VAC 3 phase 60Hz sinewave
output, 94% (CEC) efficiency, overload ratings of 105 to
115% = 10min; 115 to 125% = 1min; 125 to 150% = 200ms, each
inverter: 31.5"W x 85.04"H x 31.5"D, 1399.9 Lbs.,
Certifications: ETL listed conforming to UL1741/UL1741SA,
UL9540, CPUC RULE 21, IEEE1547, HECO RULE14H, CEC, CSA22.2,
HECO CGS, HECO CSS; Protection: OTP, AC OVP/UVP, OFP/UFP,
EPO, AC Phase Reverse, Fan/Relay Failure, OLP, GFDI,
Anti-islanding |
| Sinexcel |
184-1020-100800 |
100kVA Modular bi-directional
grid-interactive/off-grid energy storage inverter with local
touch screen control, compatible with engine-generator based
off-grid systems (virtual synchronous generator - VSG),
equipped with (2) PCS-AC-50k power conversion module(s) and
built in transformer for 3-phase 4-wire applications,
IP20/NEMA 1 with forced air cooling, battery operational
range between 500VDC to 850VDC, 480VAC 3 phase 60Hz input /
480VAC 3 phase 60Hz sinewave output, 94% (CEC) efficiency,
overload ratings of 105 to 115% = 10min; 115 to 125% = 1min;
125 to 150% = 200ms, each inverter: 31.5"W x 85.04"H x
31.5"D, 1499.1 Lbs., Certifications: ETL listed conforming
to UL1741/UL1741SA, UL9540, CPUC RULE 21, IEEE1547, HECO
RULE14H, CEC, CSA22.2, HECO CGS, HECO CSS; Protection: OTP,
AC OVP/UVP, OFP/UFP, EPO, AC Phase Reverse, Fan/Relay
Failure, OLP, GFDI, Anti-islanding |
| Sinexcel |
184-1020-100900 |
150kVA rated (complete Power
System Frame only with no power modules) Modular
bi-directional grid-interactive/off-grid energy storage
inverter with local touch screen control, compatible with
engine-generator based off-grid systems (virtual synchronous
generator - VSG), equipped with (0) PCS-AC-50k power
conversion module(s) and built in transformer for 3-phase
4-wire applications, IP20/NEMA 1 with forced air cooling,
battery operational range between 500VDC to 850VDC, 480VAC 3
phase 60Hz input / 480VAC 3 phase 60Hz sinewave output,
94.5% (CEC) efficiency, overload ratings of 105 to 115% =
10min; 115 to 125% = 1min; 125 to 150% = 200ms, each
inverter: 31.5"W x 85.04"H x 31.5"D, 1708.6 Lbs.,
Certifications: ETL listed conforming to UL1741/UL1741SA,
UL9540, CPUC RULE 21, IEEE1547, HECO RULE14H, CEC, CSA22.2,
HECO CGS, HECO CSS; Protection: OTP, AC OVP/UVP, OFP/UFP,
EPO, AC Phase Reverse, Fan/Relay Failure, OLP, GFDI,
Anti-islanding |
| Sinexcel |
184-1020-101000 |
50kVA (expandable to 150kVA)
Modular bi-directional grid-interactive/off-grid energy
storage inverter with local touch screen control, compatible
with engine-generator based off-grid systems (virtual
synchronous generator - VSG), equipped with (1) PCS-AC-50k
power conversion module(s) and built in transformer for
3-phase 4-wire applications, IP20/NEMA 1 with forced air
cooling, battery operational range between 500VDC to 850VDC,
480VAC 3 phase 60Hz input / 480VAC 3 phase 60Hz sinewave
output, 94.5% (CEC) efficiency, overload ratings of 105 to
115% = 10min; 115 to 125% = 1min; 125 to 150% = 200ms, each
inverter: 31.5"W x 85.04"H x 31.5"D, 1807.8 Lbs.,
Certifications: ETL listed conforming to UL1741/UL1741SA,
UL9540, CPUC RULE 21, IEEE1547, HECO RULE14H, CEC, CSA22.2,
HECO CGS, HECO CSS; Protection: OTP, AC OVP/UVP, OFP/UFP,
EPO, AC Phase Reverse, Fan/Relay Failure, OLP, GFDI,
Anti-islanding |
| Sinexcel |
184-1020-101100 |
100kVA (expandable to 150kVA)
Modular bi-directional grid-interactive/off-grid energy
storage inverter with local touch screen control, compatible
with engine-generator based off-grid systems (virtual
synchronous generator - VSG), equipped with (2) PCS-AC-50k
power conversion module(s) and built in transformer for
3-phase 4-wire applications, IP20/NEMA 1 with forced air
cooling, battery operational range between 500VDC to 850VDC,
480VAC 3 phase 60Hz input / 480VAC 3 phase 60Hz sinewave
output, 94.5% (CEC) efficiency, overload ratings of 105 to
115% = 10min; 115 to 125% = 1min; 125 to 150% = 200ms, each
inverter: 31.5"W x 85.04"H x 31.5"D, 1907 Lbs.,
Certifications: ETL listed conforming to UL1741/UL1741SA,
UL9540, CPUC RULE 21, IEEE1547, HECO RULE14H, CEC, CSA22.2,
HECO CGS, HECO CSS; Protection: OTP, AC OVP/UVP, OFP/UFP,
EPO, AC Phase Reverse, Fan/Relay Failure, OLP, GFDI,
Anti-islanding |
| Sinexcel |
184-1020-101200 |
150kVA Modular bi-directional
grid-interactive/off-grid energy storage inverter with local
touch screen control, compatible with engine-generator based
off-grid systems (virtual synchronous generator - VSG),
equipped with (3) PCS-AC-50k power conversion module(s) and
built in transformer for 3-phase 4-wire applications,
IP20/NEMA 1 with forced air cooling, battery operational
range between 500VDC to 850VDC, 480VAC 3 phase 60Hz input /
480VAC 3 phase 60Hz sinewave output, 94.5% (CEC) efficiency,
overload ratings of 105 to 115% = 10min; 115 to 125% = 1min;
125 to 150% = 200ms, each inverter: 31.5"W x 85.04"H x
31.5"D, 2006.2 Lbs., Certifications: ETL listed conforming
to UL1741/UL1741SA, UL9540, CPUC RULE 21, IEEE1547, HECO
RULE14H, CEC, CSA22.2, HECO CGS, HECO CSS; Protection: OTP,
AC OVP/UVP, OFP/UFP, EPO, AC Phase Reverse, Fan/Relay
Failure, OLP, GFDI, Anti-islanding |
| Sinexcel |
184-1020-101300 |
250kVA rated (complete Power
System Frame only with no power modules) Modular
bi-directional grid-interactive/off-grid energy storage
inverter with local touch screen control, compatible with
engine-generator based off-grid systems (virtual synchronous
generator - VSG), equipped with (0) PCS-AC-50k power
conversion module(s) and built in transformer for 3-phase
4-wire applications, IP20/NEMA 1 with forced air cooling,
battery operational range between 500VDC to 850VDC, 480VAC 3
phase 60Hz input / 480VAC 3 phase 60Hz sinewave output, 95%
(CEC) efficiency, overload ratings of 105 to 115% = 10min;
115 to 125% = 1min; 125 to 150% = 200ms, each inverter:
47.24"W x 85.04"H x 31.5"D, 2325.9 Lbs., Certifications: ETL
listed conforming to UL1741/UL1741SA, UL9540, CPUC RULE 21,
IEEE1547, HECO RULE14H, CEC, CSA22.2, HECO CGS, HECO CSS;
Protection: OTP, AC OVP/UVP, OFP/UFP, EPO, AC Phase Reverse,
Fan/Relay Failure, OLP, GFDI, Anti-islanding |
| Sinexcel |
184-1020-101400 |
50kVA (expandable to 250kVA)
Modular bi-directional grid-interactive/off-grid energy
storage inverter with local touch screen control, compatible
with engine-generator based off-grid systems (virtual
synchronous generator - VSG), equipped with (1) PCS-AC-50k
power conversion module(s) and built in transformer for
3-phase 4-wire applications, IP20/NEMA 1 with forced air
cooling, battery operational range between 500VDC to 850VDC,
480VAC 3 phase 60Hz input / 480VAC 3 phase 60Hz sinewave
output, 95% (CEC) efficiency, overload ratings of 105 to
115% = 10min; 115 to 125% = 1min; 125 to 150% = 200ms, each
inverter: 47.24"W x 85.04"H x 31.5"D, 2425.1 Lbs.,
Certifications: ETL listed conforming to UL1741/UL1741SA,
UL9540, CPUC RULE 21, IEEE1547, HECO RULE14H, CEC, CSA22.2,
HECO CGS, HECO CSS; Protection: OTP, AC OVP/UVP, OFP/UFP,
EPO, AC Phase Reverse, Fan/Relay Failure, OLP, GFDI,
Anti-islanding |
| Sinexcel |
184-1020-101500 |
100kVA (expandable to 250kVA)
Modular bi-directional grid-interactive/off-grid energy
storage inverter with local touch screen control, compatible
with engine-generator based off-grid systems (virtual
synchronous generator - VSG), equipped with (2) PCS-AC-50k
power conversion module(s) and built in transformer for
3-phase 4-wire applications, IP20/NEMA 1 with forced air
cooling, battery operational range between 500VDC to 850VDC,
480VAC 3 phase 60Hz input / 480VAC 3 phase 60Hz sinewave
output, 95% (CEC) efficiency, overload ratings of 105 to
115% = 10min; 115 to 125% = 1min; 125 to 150% = 200ms, each
inverter: 47.24"W x 85.04"H x 31.5"D, 2524.3 Lbs.,
Certifications: ETL listed conforming to UL1741/UL1741SA,
UL9540, CPUC RULE 21, IEEE1547, HECO RULE14H, CEC, CSA22.2,
HECO CGS, HECO CSS; Protection: OTP, AC OVP/UVP, OFP/UFP,
EPO, AC Phase Reverse, Fan/Relay Failure, OLP, GFDI,
Anti-islanding |
| Sinexcel |
184-1020-101600 |
150kVA (expandable to 250kVA)
Modular bi-directional grid-interactive/off-grid energy
storage inverter with local touch screen control, compatible
with engine-generator based off-grid systems (virtual
synchronous generator - VSG), equipped with (3) PCS-AC-50k
power conversion module(s) and built in transformer for
3-phase 4-wire applications, IP20/NEMA 1 with forced air
cooling, battery operational range between 500VDC to 850VDC,
480VAC 3 phase 60Hz input / 480VAC 3 phase 60Hz sinewave
output, 95% (CEC) efficiency, overload ratings of 105 to
115% = 10min; 115 to 125% = 1min; 125 to 150% = 200ms, each
inverter: 47.24"W x 85.04"H x 31.5"D, 2623.5 Lbs.,
Certifications: ETL listed conforming to UL1741/UL1741SA,
UL9540, CPUC RULE 21, IEEE1547, HECO RULE14H, CEC, CSA22.2,
HECO CGS, HECO CSS; Protection: OTP, AC OVP/UVP, OFP/UFP,
EPO, AC Phase Reverse, Fan/Relay Failure, OLP, GFDI,
Anti-islanding |
| Sinexcel |
184-1020-101700 |
200kVA (expandable to 250kVA)
Modular bi-directional grid-interactive/off-grid energy
storage inverter with local touch screen control, compatible
with engine-generator based off-grid systems (virtual
synchronous generator - VSG), equipped with (4) PCS-AC-50k
power conversion module(s) and built in transformer for
3-phase 4-wire applications, IP20/NEMA 1 with forced air
cooling, battery operational range between 500VDC to 850VDC,
480VAC 3 phase 60Hz input / 480VAC 3 phase 60Hz sinewave
output, 95% (CEC) efficiency, overload ratings of 105 to
115% = 10min; 115 to 125% = 1min; 125 to 150% = 200ms, each
inverter: 47.24"W x 85.04"H x 31.5"D, 2722.7 Lbs.,
Certifications: ETL listed conforming to UL1741/UL1741SA,
UL9540, CPUC RULE 21, IEEE1547, HECO RULE14H, CEC, CSA22.2,
HECO CGS, HECO CSS; Protection: OTP, AC OVP/UVP, OFP/UFP,
EPO, AC Phase Reverse, Fan/Relay Failure, OLP, GFDI,
Anti-islanding |
| Sinexcel |
184-1020-101800 |
250kVA Modular bi-directional
grid-interactive/off-grid energy storage inverter with local
touch screen control, compatible with engine-generator based
off-grid systems (virtual synchronous generator - VSG),
equipped with (5) PCS-AC-50k power conversion module(s) and
built in transformer for 3-phase 4-wire applications,
IP20/NEMA 1 with forced air cooling, battery operational
range between 500VDC to 850VDC, 480VAC 3 phase 60Hz input /
480VAC 3 phase 60Hz sinewave output, 95% (CEC) efficiency,
overload ratings of 105 to 115% = 10min; 115 to 125% = 1min;
125 to 150% = 200ms, each inverter: 47.24"W x 85.04"H x
31.5"D, 2821.9 Lbs., Certifications: ETL listed conforming
to UL1741/UL1741SA, UL9540, CPUC RULE 21, IEEE1547, HECO
RULE14H, CEC, CSA22.2, HECO CGS, HECO CSS; Protection: OTP,
AC OVP/UVP, OFP/UFP, EPO, AC Phase Reverse, Fan/Relay
Failure, OLP, GFDI, Anti-islanding |
| Sinexcel |
184-1020-101900 |
50kW AC to DC / DC to AC power
conversion module for use with PWS1-50k through PWS1-250k
series bi-directional energy storage inverters, IP20/NEMA 1
with forced air cooling, 480VAC 3 phase 60Hz input / 480VAC
3 phase 60Hz sinewave output, 95% (CEC) efficiency, overload
ratings of , each inverter: 19.02"W x 8.66"H x 23.62"D, 99.2
Lbs., Certifications: |
| Sinexcel |
184-1030-100100 |
500kVA rated (complete Power
System Frame only with no power modules) Modular
bi-directional grid-interactive/off-grid energy storage
inverter with touch-screen control, equipped with (0)
PCS-AC-62.5kVA power conversion modules expandable in same
cabinet system up to 500kVA, compatible with
engine-generator based off-grid systems (VSG), 3-phase
3-wire [external transformer required and not included for
4-wire/nuetral wiring applications], IP20/NEMA 1 with forced
air cooling, battery operational range between 630VDC to
900VDC, 480VAC 3 phase 60Hz input / 480VAC 3 phase 60Hz
sinewave output, 98.2% efficiency, overload ratings of 105
to 115% = 10min; 115 to 125% = 1min; 125 to 150% = 200ms,
each inverter: 43.31"W x 78.74"H x 31.5"D, 529.1 Lbs.,
Certifications: ETL listed conforming to UL1741/UL 1741SA/UL
9540, CPUC RULE 21,CSA 22.2; Protection: OTP, AC OVP/UVP,
OFP/UFP, EPO, AC Phase Reverse, Fan/Relay Failure, OLP,
GFDI, Anti-islanding |
| Sinexcel |
184-1030-100200 |
62.5kVA Modular bi-directional
grid-interactive/off-grid energy storage inverter with
touch-screen control, equipped with (1) PCS-AC-62.5kVA power
conversion modules expandable in same cabinet system up to
500kVA, compatible with engine-generator based off-grid
systems (VSG), 3-phase 3-wire [external transformer required
and not included for 4-wire/nuetral wiring applications],
IP20/NEMA 1 with forced air cooling, battery operational
range between 630VDC to 900VDC, 480VAC 3 phase 60Hz input /
480VAC 3 phase 60Hz sinewave output, 98.2% efficiency,
overload ratings of 105 to 115% = 10min; 115 to 125% = 1min;
125 to 150% = 200ms, each inverter: 43.31"W x 78.74"H x
31.5"D, 628.3 Lbs., Certifications: ETL listed conforming to
UL1741/UL 1741SA/UL 9540, CPUC RULE 21,CSA 22.2; Protection:
OTP, AC OVP/UVP, OFP/UFP, EPO, AC Phase Reverse, Fan/Relay
Failure, OLP, GFDI, Anti-islanding |
| Sinexcel |
184-1030-100300 |
125kVA Modular bi-directional
grid-interactive/off-grid energy storage inverter with
touch-screen control, equipped with (2) PCS-AC-62.5kVA power
conversion modules expandable in same cabinet system up to
500kVA, compatible with engine-generator based off-grid
systems (VSG), 3-phase 3-wire [external transformer required
and not included for 4-wire/nuetral wiring applications],
IP20/NEMA 1 with forced air cooling, battery operational
range between 630VDC to 900VDC, 480VAC 3 phase 60Hz input /
480VAC 3 phase 60Hz sinewave output, 98.2% efficiency,
overload ratings of 105 to 115% = 10min; 115 to 125% = 1min;
125 to 150% = 200ms, each inverter: 43.31"W x 78.74"H x
31.5"D, 727.5 Lbs., Certifications: ETL listed conforming to
UL1741/UL 1741SA/UL 9540, CPUC RULE 21,CSA 22.2; Protection:
OTP, AC OVP/UVP, OFP/UFP, EPO, AC Phase Reverse, Fan/Relay
Failure, OLP, GFDI, Anti-islanding |
| Sinexcel |
184-1030-100400 |
187.5kVA Modular bi-directional
grid-interactive/off-grid energy storage inverter with
touch-screen control, equipped with (3) PCS-AC-62.5kVA power
conversion modules expandable in same cabinet system up to
500kVA, compatible with engine-generator based off-grid
systems (VSG), 3-phase 3-wire [external transformer required
and not included for 4-wire/nuetral wiring applications],
IP20/NEMA 1 with forced air cooling, battery operational
range between 630VDC to 900VDC, 480VAC 3 phase 60Hz input /
480VAC 3 phase 60Hz sinewave output, 98.2% efficiency,
overload ratings of 105 to 115% = 10min; 115 to 125% = 1min;
125 to 150% = 200ms, each inverter: 43.31"W x 78.74"H x
31.5"D, 826.7 Lbs., Certifications: ETL listed conforming to
UL1741/UL 1741SA/UL 9540, CPUC RULE 21,CSA 22.2; Protection:
OTP, AC OVP/UVP, OFP/UFP, EPO, AC Phase Reverse, Fan/Relay
Failure, OLP, GFDI, Anti-islanding |
| Sinexcel |
184-1030-100500 |
250kVA Modular bi-directional
grid-interactive/off-grid energy storage inverter with
touch-screen control, equipped with (4) PCS-AC-62.5kVA power
conversion modules expandable in same cabinet system up to
500kVA, compatible with engine-generator based off-grid
systems (VSG), 3-phase 3-wire [external transformer required
and not included for 4-wire/nuetral wiring applications],
IP20/NEMA 1 with forced air cooling, battery operational
range between 630VDC to 900VDC, 480VAC 3 phase 60Hz input /
480VAC 3 phase 60Hz sinewave output, 98.2% efficiency,
overload ratings of 105 to 115% = 10min; 115 to 125% = 1min;
125 to 150% = 200ms, each inverter: 43.31"W x 78.74"H x
31.5"D, 925.9 Lbs., Certifications: ETL listed conforming to
UL1741/UL 1741SA/UL 9540, CPUC RULE 21,CSA 22.2; Protection:
OTP, AC OVP/UVP, OFP/UFP, EPO, AC Phase Reverse, Fan/Relay
Failure, OLP, GFDI, Anti-islanding |
| Sinexcel |
184-1030-100600 |
312.5kVA Modular bi-directional
grid-interactive/off-grid energy storage inverter with
touch-screen control, equipped with (5) PCS-AC-62.5kVA power
conversion modules expandable in same cabinet system up to
500kVA, compatible with engine-generator based off-grid
systems (VSG), 3-phase 3-wire [external transformer required
and not included for 4-wire/nuetral wiring applications],
IP20/NEMA 1 with forced air cooling, battery operational
range between 630VDC to 900VDC, 480VAC 3 phase 60Hz input /
480VAC 3 phase 60Hz sinewave output, 98.2% efficiency,
overload ratings of 105 to 115% = 10min; 115 to 125% = 1min;
125 to 150% = 200ms, each inverter: 43.31"W x 78.74"H x
31.5"D, 1025.1 Lbs., Certifications: ETL listed conforming
to UL1741/UL 1741SA/UL 9540, CPUC RULE 21,CSA 22.2;
Protection: OTP, AC OVP/UVP, OFP/UFP, EPO, AC Phase Reverse,
Fan/Relay Failure, OLP, GFDI, Anti-islanding |
| Sinexcel |
184-1030-100700 |
375kVA Modular bi-directional
grid-interactive/off-grid energy storage inverter with
touch-screen control, equipped with (6) PCS-AC-62.5kVA power
conversion modules expandable in same cabinet system up to
500kVA, compatible with engine-generator based off-grid
systems (VSG), 3-phase 3-wire [external transformer required
and not included for 4-wire/nuetral wiring applications],
IP20/NEMA 1 with forced air cooling, battery operational
range between 630VDC to 900VDC, 480VAC 3 phase 60Hz input /
480VAC 3 phase 60Hz sinewave output, 98.2% efficiency,
overload ratings of 105 to 115% = 10min; 115 to 125% = 1min;
125 to 150% = 200ms, each inverter: 43.31"W x 78.74"H x
31.5"D, 1124.4 Lbs., Certifications: ETL listed conforming
to UL1741/UL 1741SA/UL 9540, CPUC RULE 21,CSA 22.2;
Protection: OTP, AC OVP/UVP, OFP/UFP, EPO, AC Phase Reverse,
Fan/Relay Failure, OLP, GFDI, Anti-islanding |
| Sinexcel |
184-1030-100800 |
437.5kVA Modular bi-directional
grid-interactive/off-grid energy storage inverter with
touch-screen control, equipped with (7) PCS-AC-62.5kVA power
conversion modules expandable in same cabinet system up to
500kVA, compatible with engine-generator based off-grid
systems (VSG), 3-phase 3-wire [external transformer required
and not included for 4-wire/nuetral wiring applications],
IP20/NEMA 1 with forced air cooling, battery operational
range between 630VDC to 900VDC, 480VAC 3 phase 60Hz input /
480VAC 3 phase 60Hz sinewave output, 98.2% efficiency,
overload ratings of 105 to 115% = 10min; 115 to 125% = 1min;
125 to 150% = 200ms, each inverter: 43.31"W x 78.74"H x
31.5"D, 1223.6 Lbs., Certifications: ETL listed conforming
to UL1741/UL 1741SA/UL 9540, CPUC RULE 21,CSA 22.2;
Protection: OTP, AC OVP/UVP, OFP/UFP, EPO, AC Phase Reverse,
Fan/Relay Failure, OLP, GFDI, Anti-islanding |
| Sinexcel |
184-1030-100900 |
500kVA Modular bi-directional
grid-interactive/off-grid energy storage inverter with
touch-screen control, equipped with (8) PCS-AC-62.5kVA power
conversion modules expandable in same cabinet system up to
500kVA, compatible with engine-generator based off-grid
systems (VSG), 3-phase 3-wire [external transformer required
and not included for 4-wire/nuetral wiring applications],
IP20/NEMA 1 with forced air cooling, battery operational
range between 630VDC to 900VDC, 480VAC 3 phase 60Hz input /
480VAC 3 phase 60Hz sinewave output, 98.2% efficiency,
overload ratings of 105 to 115% = 10min; 115 to 125% = 1min;
125 to 150% = 200ms, each inverter: 43.31"W x 78.74"H x
31.5"D, 1322.8 Lbs., Certifications: ETL listed conforming
to UL1741/UL 1741SA/UL 9540, CPUC RULE 21,CSA 22.2;
Protection: OTP, AC OVP/UVP, OFP/UFP, EPO, AC Phase Reverse,
Fan/Relay Failure, OLP, GFDI, Anti-islanding |
| Sinexcel |
184-1030-101000 |
62.5kVA AC to DC / DC to AC
power conversion module for use with PWS1-500k series
bi-directional energy storage inverters, IP20/NEMA 1 with
forced air cooling, 480VAC 3 phase 60Hz input / 480VAC 3
phase 60Hz sinewave output, 98.2% efficiency, overload
ratings of 105 to 115% = 10min; 115 to 125% = 1min; 125 to
150% = 200ms, each inverter: 19.02"W x 8.66"H x 23.62"D,
99.2 Lbs., Certifications: |
| Sinexcel |
184-1030-101100 |
Static transfer switch option
for PWS1 energy storage inverters |
Connect With Us
Contact Us Today For Support - 954.903.4040
